Introduction: The Wooden Pallet Hydraulic Press Machi […]
| Dimensions: | 1200 x 1000 x 150mm |
| Weight Capacity: | 1500 kg (static) |
| Material: | Compressed Wood Chips |
| Color: | Natural Wood |
The Wooden Pallet Hydraulic Press Machine is an industrial equipment specifically designed for producing wooden or biomass-material pallets. Utilizing high-pressure hydraulic systems and molds, it combines wood chips, wood fibers, or other biomass materials with binders to compress them into high-density, high-strength, and eco-friendly pallets.
Environmental Pallet Production: Replaces traditional wooden or plastic pallets, suitable for logistics, warehousing, and export packaging.
Biomass Material Utilization: Processes agricultural and forestry waste (e.g., sawdust, straw, bamboo chips), aligning with circular economy policies.
Customized Products: Produces non-standard pallets, heavy-duty pallets, and pallets with moisture-resistant or fire-retardant functions.
Servo-hydraulic systems reduce energy consumption by 30%-50%, lowering operational costs.
Automated processes from material feeding to demolding minimize manual intervention.
Precise pressure and temperature control ensures uniform pallet density and strength.
Molded pallet hot press is a new type of molded pallet production equipment, the use of hot pressing process of one-time molding, pallet hydraulic press has the advantages of high efficiency, one-time molding, material saving, high strength, environmental protection and energy saving.
Depending on the size of the pressed pallet flower pattern, can be configured with different molds, specific can consult customer service.
I. Raw material preparation
Choose suitable raw materials, such as wood shavings, plant straw and so on. Preliminary processing of raw materials, including cutting, chipping and other steps for subsequent crushing and mixing.
2, crushing and mixing
The preliminary processed raw materials are crushed to the appropriate particle size and automatically proportioned for transfer as required.
Mixing of the proportioned raw materials with adhesives. The mixing process should ensure that the adhesive is evenly distributed in the raw material to improve the strength and stability of the pallet.
3, drying and cooling
The mixed raw materials are dried at high temperature to reduce their moisture content to ensure the stability and quality of the pallet in the moulding process.
After drying, the raw material should be cooled for subsequent moulding operations.
4.Moulding
The dried and cooled mix is conveyed to the laying machine in set quantities. The spreader spreads the mix evenly in the mould in preparation for moulding.
A hydraulic press for wood chip pallets is used to apply high temperature and pressure to the mix in the mould. The hydraulic press provides a strong compressive force that binds and cures the mix in the mould.
After moulding, the pallet is automatically removed from the mould.
wood-pallet-machine-Wood-Chip-Pallets-Compressed-Pallet-Moulding-Machine-Production-Line-Customer-site[/caption]
